400 series wall-mounted cooker hood 120 cm Stainless steel

AW442120

Professional technology hood combined with classic Gaggenau design

Highly efficient extraction of cooking vapours due to large vapour collection area

Motorless, can be combined with Gaggenau BLDC remote fan units

Angled baffle filter with high grease absorption

Function for automatic, sensor-controlled power adjustment depending on the build-up of cooking vapours

Dimmable, neutral white surface LED light for ideal illumination of the whole cooktop

Air extraction or air recirculation system

Air recirculation module with activated charcoal filter: quiet and highly efficient air recirculation solution with odour reduction as in air extraction mode and long replacement intervals

Power levels depend on the remote fan unit, see table on page XX.

3 electronically controlled power levels and 1 intensive mode.

Automatic function with sensor-controlled run-on function.

Grease filter saturation indicator.

Baffle filter, dishwasher-safe.

Neutral white surface LED light (3500 K), continuously dimmable.

Lamp output 3 x LED light bars 10W.

Illuminance 940 lx.

Easy mounting system for simple installation and alignment.

Consumption data is referred to a configuration with the remote fan unit AR 400 143.

Energy consumption 48.1 kWh/year.

Ventilation efficiency class A.

Ilumination efficiency class B.

Grease filter efficiency class B.

Sound level min. 47 dB / max. 64 dB normal mode.

Refer to the table on page XX for the matching remote fan units for air recirculation or air extraction mode.

The two-part chimney must be ordered as an installation accessory.

Connection to the respective appliances via network cable.

Clearance above gas appliances min. 70 cm.

Clearance above electric appliances min. 60 cm.

Air recirculation module with 2 activated charcoal filters is installed in the inner chimney. Special air recirculation chimneys are available for this.

When installing a ventilation hood with air extraction mode and a chimney-vented fireplace, the power supply line of the ventilation appliance needs a suitable safety switch.
