200 series Vario downdraft ventilation 15 cm BlackVL200120
Replacement for
VL041115
1 / 29
+ 14
200 series Vario downdraft ventilation 15 cm BlackVL200120
Replacement for
VL041115
Find a local Dealer
Technical Overview
Sound power level extraction (max)
71 dB
Maximum output air extraction
550 m³/h
Color body
Black
Material body
Alu
Built-in / Free-standing
Built-in
Width of appliance
15 cm
Specifications
Can be combined with the cooktops of the Vario 200 series to a harmonic unity
Function for automatic, sensor-controlled power adjustment depending on the build-up of cooking vapours
Air extraction or air recirculation system
Power levels depend on the remote fan unit, see table on page XX.
3 electronically controlled power levels and 1 intensive mode.
Grease filter and activated charcoal filter saturation indicator.
Airflow-optimised interior for efficient air circulation.
Interval ventilation, 6 min.
Consumption data is referred to a configuration with the remote fan unit AR 403 122.
Energy consumption 48.3 kWh/year.
Ventilation efficiency class A.
Ilumination efficiency class -.
Grease filter efficiency class B.
Sound level min. 56 dB / max. 71 dB normal mode.
For each VL one remote fan unit is recommended.
When having installed the ventilation moulding LS 041 001 the wok pan WP 400 001 can not be used.
When installing a ventilation hood with air extraction mode and a chimney-vented fireplace, the power supply line of the ventilation appliance needs a suitable safety switch.
Please read additional planning notes on page xx.
